Displays & Receivers

StarFire 6000

The StarFire 6000 with SF3 signal has in-season repeatability (9 months), although the correction signal is received from the geo-stationary StarFire satellites. This is achieved as the SF6000 with SF3 accounts for this tectonic plate movement using mathematic/algorithms and predictive models. It is perfect for certain producers who need in season accuracy, but not long-term repeatability.

StarFire 6000 Receiver repeatability:

  • SF1: no repeatability, position drifts over time
  • SF3: +/- 3-cm (1.2-in.) in-season repeatability (where applicable)
  • Radio RTK: +/- 2.5-cm (1.0-in.) long-term repeatability

StarFire 1 Signal

The best entry-level signal is now even better. You profit from a +/- 15cm pass-to-pass accuracy, previously +/- 23cm. Free of charge and with GLONASS included.

The perfect starting point for tillage, grassland applications and harvesting:

  • +/- 15cm pass-to-pass accuracy
  • Multiple StarFire Tracking
  • No license fees
  • Terrain Compensation Module (TCM) in base model
  • GLONASS in base model

StarFire 3 Signal

The SF3 delivers +/- 3cm pass-to-pass accuracy and 9 months in-season repeatability. Even better, the pull-in time is up to 4 times faster than with SF2. So you can spend more time working in field instead of waiting on the headland or compromising quality.

More accuracy. Ideal for seeding and planting:

  • +/- 3cm pass-to-pass accuracy
  • 100% accuracy in less than 30 minutes
  • 9 months in-season repeatability
  • Flexible licence periods
  • Easily upgradeable


John Deere Mobile RTK uses the John Deere Mobile RTK network and the John Deere Mobile RTK Signal differential correction signal to obtain real-time kinematic (RTK) accuracy. Since this is a cellular technology, the machine uses the modular telematics gateway (MTG 4G LTE or 3G) or John Deere Mobile RTK modem (4G LTE and 2G) instead of an RTK radio. Using a cellular data connection, the MTG or John Deere Mobile RTK modem connects to a central server to receive the John Deere Mobile RTK Signal from a number of base stations spread throughout the countryside. This central server, cellular towers, and base stations provide RTK accuracy which has been calculated from a number of base stations that make up the network.

The following receivers are required to complete a John Deere Mobile RTK system:

  • StarFireâ„¢ 6000 (SF3 ready) with RTK ready activation
  • StarFire 3000 (SF2 ready) with RTK ready activation

Generation 4 Display Options

GreenStar 4 Extended monitor

The Gen 4 Extended Monitor provides a secondary monitor solution for producers who want two monitors to manage their machine and precision ag applications on their 4600 CommandCenter or 4640 Universal Display. Adding the second monitor gives producers in display-intensive operations the ability to view and adjust more of their operations at once.

An Extended Monitor provides the following benefits:

  • One easy-to-use system
  • Make adjustments on the go with either monitor in one operating system
  • Simplified in-cab operating experience
  • Maximize uptime and minimize setup time with quick and easy plug and play
  • Increased customization and viewable access
